Bogen HTA125A MOSFET Power Amp 125W - Bogen Audio Amplifier

The Bogen HTA125A MOSFET Power Amp is a high-performance audio amplifier that utilizes Power MOSFET technology. With its unique characteristics, this amplifier provides superior performance and reliability compared to other transistor-based amplifiers. It offers higher efficiency, reduced heat, simpler overall design, and smaller size and weight.

Features:

• Peak power per channel: 250W
• Total Harmonic Distortion (THD): 0.5%
• Signal-to-Noise Ratio (SNR): 90dB
• Frequency range: 20Hz - 20,000Hz
• DC-in jack: Yes
• Product color: Black
• Connectivity technology: Wired
• AC input voltage: 100-127V
• AC input frequency: 50Hz - 60Hz
• Width: 483mm
• Depth: 279mm
• Height: 133mm
• Weight: 22700g
• LED indicators: Yes
• User guide: Yes
• Manual: Yes
• Volume control: Rotary
• Output impedance: 8 ohms

Specifications:

• Power output: 125 watts (rms continuous output)
• Total harmonic distortion: Less than 0.5% from 20Hz to 20,000Hz
• Input signal required for full rated output: 500mV
• Input impedances:
  • High-impedance (50,000 ohms) unbalanced
  • Low impedance (500/600 ohms, balanced or unbalanced) with optional accessory transformer Model TL600
• Load impedances: 4 ohms, 8 ohms, 25VCT, and 70 volts
• Residual hum and noise: At least 90dB below rated output
• Output regulation: Better than 2dB from no load to full load
• Thermal protection: Yes
• Additional failure-preventive devices:
  • Overload limiting
  • Short circuit protection
  • Slo-Blo fuse

Learn More:

For more information about MOSFET amplifiers, please visit the MOSFET page on Wikipedia.

For more details about Bogen Audio Amplifiers, please refer to the Bogen Communications page on Wikipedia.

Specifications

Product: Accu-Tech HTA125A MOSFET Power Amp 125W - Bogen Audio Amplifier

Brand: Bogen

Model: HTA125A

Additional Shipping Information:

Shipping Weight: 40.40 lb

Shipping Height: 10.00 in

Shipping Width: 16.00 in

Shipping Length: 22.00 in
